Pressure control unit M170 OT/Awith pressure gauge complete by Braglia with manual operation for use in high pressure ranges up to 50 bar, flow rate 150 l/min. Suitable for use with sprayers and in the sprayer boom. Precise and reliable pressure adjustment even at lower pressure.
Material and design:
Brass and aluminum, nickel-plated and corrosion-free
highly resistant plastics
Piston and seat made of vacuum-hardened stainless steel
with ball made of AISI 304, seal BUNA N
Inlet ¾ "IG
Outlet 2x ½ "AG
Flow back hose nozzle ø 25 mm
