Piston diaphragm pump from the manufacturer Comet from Italy. The pump has got 4 cylinders with an effiency of 138 l/min at a max. pressure of 20 bar. The delivery takes place without pressurestat and with a pump socket, optional with safety valve. The piston diaphragm pump has a 1 ⅜" power-drive both sides for 550 RPM or a 1 ⅜" power-drive with through shaft cylinder ø 30 mm.
Connections:
Suction tail 90° ø 40 mm
Delivery tail 90° ø 25 mm
Technical data, see table – spare parts and spare part list for download. Please select drive.
Recommendation for suitable power units at hydraulic drive:
