Arag Bravo180S for multi-row sprayer, hydraulic control
Bravo 180S for multi-row sprayer is the smallest computer belonging to Arag Precision Farming range but still offering high performances. A compact and cost-effective tool but extraorfinarily efficient and precise to meet all requirements of small-medium farming machine operators.
- Special software for multi-row orchard sprayer
- Special keys for row width and spray rate
- Operating pressure display
- Special key to recall up to 5 present spray rate values
- Displayable data: spray rate, speed, calculated pressure, flow rate, distributed amount, tank level, covered area, spraying time, covered distance
- Alarms for: preset spray rate not reached, tank low level
- Temporary increase and reduction of distributed fluid
- Storage of up to 5 job reports
- LED indicators for valve status
- Inputs for flow rate and speed signals
- Outputs to control up to 5 boom sections, control valve, main valve and foam marker
- Selectable language: Italian, English, French, Portuguese, Spanish, Russian, German and Polish
- Selectable units of measurement: International (ha, km/h), US (Ac, mph) and golf course units (US Gallon/1000sqft)
- Backlit alphanumeric display - 2 lines x 16 digits
- Different types of sensors can be connected
- Connection port for printer or PC
- Power supply: 12Vdc
- Computer
- Bayonet bracket
- Panel outlet for power cable
- Inductive speed sensor with 5 m cable
- Power cable, 3 m
- Valve and senor cable, 4 m
- Connection cable for hydraulic valves, 10 m
- User’s and quick guide
- GPS Speed ??Sensor
- Extension cable, 3 m
- Sensor extension cable, 3 m
- Sensor extension cable, 5 m
- Pressure sensor
- Cables for general control
- Foam marker
- Level sensor
- Sealing cap for cable connector boom section valves
