SAFI Ball Valve 2-way Serie 2008 compact with thread
Manual, compact 2-way ball valve series 2008 from SAFI with female thread BSP ½" and ¾" on both sides. Made of PPGF (Polypropylene glass fiber reinforced), ball material PVDF. Optionally, the ball valve with EPDM or FPM seals available, suitable for a working pressure up to 10 bar.
Main features
Standard & Approvals
Options
Main features
- Full Bore
- Optimized Mechanical resistance due to the use of PPGF reinforced with Fibreglass
- Reduced size
- Suited for Actuation
- Polypropylene contains 20 % of borosilicate glass reinforced of type «C» chemically resistant.
- Very good mechanical resistance, a good dimensional stability, can be easily machined and it is resistant to temperatures from -10°C up to 100°C.
- Its resistance to UV is improved by the addition of carbon pigments and UV stabilizers.
- Pressure range up to 10 bar
- DN 15 and 20 mm – ½" and ¾"
- Ball made of PVDF
- Seals EPDM or FPM
- Operating temperature –10°C to +100°C
- Further data see table
Standard & Approvals
Options
Product-Liability
SAFI Thermoplasc Valve Solutions
Hauptsitz AFI France
13, Av Jacques Moison - BP1
26770 TAULIGNAN
Tel : +33 (0)4 75 53 56 29
Fax : +33 (0)4 75 53 62 78
- SAFI-Datasheet-Ball-Valve (1.2 MB)
